TGP508-WIFI-WP
About this item
• Supply: AC100- 240V
• Load Current: 3A
• Sensor: Only Internal Air Sensor
• Connection: Wired
• Programmable: Weekly Programmable
• Wi-Fi enabled, supports remote app & voice control
• App Control: Tuya/Smart Life
• Voice Control: GoogleHome / Amazon Alexa / Yandex Alice
• Mounting Type: Flush Mounting
• Color: Black
• Dimensions: 86x86x14 mm
Technical Data
Model Spec
Product Display
TGP508 Wifi Alexa Underfloor Heating Thermostat is suitable for room temperature control. It controls the operating state of the floor heating equipment by comparing the ambient temperature with the set temperature, which improves comfort and achieves energy saving. This underfloor heating thermostat is equipped with buttons, which is elegant in design and easy to use. The thermostat has manual automatic, programmable and state memory functions.
This TGP508 is the most popular product at present. Users can remotely monitor and control the indoor temperature through mobile phone apps or the Internet, adjust the temperature anytime and anywhere, and improve the convenience and flexibility of use. So it suitable for various places, such as homes, offices, commercial places, etc., with flexibility and versatility.
App Control
TGP508 series WiFi Thermostat works with Tuya app and Smart Life app, you can control it via phone anywhere and anytime.
Temperature Hysteresis
This refers to the temperature value of the thermostat turning on and stopping heating. For example, the current setting temperature is 25 ℃, and the starting temperature difference is set to 0.5 ℃. Then, when the room temperature is below 24.5 ℃, the heating is turned on, and the heating is stopped when it reaches 25.5 ℃.
Weekly Programmable
The weekly programming function can set the temperature at different times.
1. Q: Can I install this thermostat by myself? Do I need to hire an electrician?
A: Regarding the installation of the thermostat, we first recommend that you operate in strict accordance with the steps in the product manual under the guidance of professionals to ensure standardized installation and stable subsequent operation of the device. If you choose to install it yourself, you must carefully read the manual in advance, fully master the installation process, wiring requirements and safety precautions before starting the operation, so as to avoid affecting the device's function or causing potential safety hazards due to improper operation.
2. Q: Why is my water floor heating not reaching the set temperature?
A: There could be several reasons. First, check if the thermostat is set correctly. Also, verify that the valves and actuators are functioning properly, and there are no blockages in the water pipes. The water temperature from the boiler might also be too low.
3. Q: What should I do if the thermostat makes a clicking sound when adjusting the temperature?
A: A normal clicking sound is typically caused by the thermostat’s internal relay switching on/off to control the connected valves or actuators—this is a sign that the thermostat is working properly. However, if the clicking is frequent or accompanied by temperature fluctuations, it may indicate a faulty relay or unstable room temperature. Check the sensor placement first; if the issue persists, contact technical support.
4. Q: How long is the product warranty period?
A: Our products come with a 2-year free warranty. If there is a quality issue (such as failure to turn on or unresponsive buttons) after you receive the goods, you can contact the after-sales customer service and provide the order number and photos of the problem. We will arrange for a replacement or repair.
